■ 4볼트 취부용 For 4 Bolt Attachment |
■ TG/MDL Motor |
|
| Type |
Rated Flow
(cm3/rev) |
Working Pressure
(kgf/cm2) |
Rev. Count
(rpm) |
| TG-195 |
195 |
206.9 |
381 |
| TG-240 |
237 |
206.9 |
314 |
| TG-280 |
280 |
206.9 |
266 |
| TG-335 |
337 |
206.9 |
221 |
| TG-405 |
405 |
172.4 |
185 |
| TG-475 |
476 |
137.9 |
157 |
| TG-530 |
529 |
137.9 |
141 |
| TG-625 |
624 |
120.7 |
120 |
| TG-785 |
786 |
103.4 |
95 |
| TG-960 |
958 |
69.0 |
78 |
|
사양 및 도면 보기
■ ORBIT Motor (2000 Series) |
| |
|
| Type |
Rated Flow
(cm3/rev) |
Working Pressure (kgf/cm2) |
Rev. count
(RPM) |
| Rated |
Max. |
| 2-080 |
80 |
210 |
310 |
850 |
| 2-100 |
100 |
210 |
310 |
690 |
| 2-125 |
130 |
185 |
310 |
550 |
| 2-160 |
160 |
150 |
260 |
430 |
| 2-200 |
195 |
135 |
260 |
350 |
| 2-250 |
245 |
110 |
260 |
280 |
| 2-315 |
305 |
100 |
260 |
250 |
| 2-390 |
395 |
80 |
170 |
230 |
|
■ MAXMA Motor (MAH/BMH)
|
|
| Type |
Rated Flow
(cm3/rev) |
Working Pressure (kgf/cm2) |
Rev. count
(RPM) |
| Rated |
Max. |
| MAH-125 |
124.9cc |
180 |
230 |
383 |
| MAH-160 |
157.2cc |
180 |
230 |
374 |
| MAH-200 |
203.2cc |
175 |
225 |
366 |
| MAH-250 |
255.9cc |
175 |
225 |
290 |
| MAH-315 |
316.0cc |
175 |
225 |
290 |
| MAH-400 |
406.4cc |
155 |
210 |
183 |
| MAH-500 |
489.2cc |
125 |
180 |
155 |
| BMH-630 |
632cc |
120 |
135 |
115 |
| BMH-800 |
804cc |
68 |
85 |
75 |
|
사양 및 도면 보기
■ RE Type
|
  |
|
|
|
|
